The all-new ALUXX aluminum frame features updated tube shaping and a lighter overall weight for improved performance on off-road terrain.
Specifications
Sizes - XS, S, M, L
Frame - ALUXX-grade aluminum, disc
Fork - GIANT SXC32-3 Coil w/Pre-load Adj & Lockout 29"/27.5" 15x110 TA XS: 80mm (27.5") Spring: soft, S: 80mm (27.5"), 100mm(29") Spring: soft, M: 100mm(/29") Spring: standard, L: 100mm(/29") Spring: standard
Handlebar - Giant Connect Trail, 31.8 XS: 690(27.5"), S: 690(27.5") 750 (29"), M: 750(29"), L: 750(29")
Stem - Giant Sport, 7 Degree XS: 40 (27.5"), S: 40(27.5"/29"), M: 50(29"), L: 50(29")
Seatpost - Giant Sport 30.9, XS: 350(27.5"), S: 350(27.5") / 375(29"), M: 375(29"), L: 375(29")
Saddle - Contact ergo
Pedals - MTB caged
Shifters - Microshift Advent 1x9 SL-M9295R
Rear Derailleur - Microshift Advent 1x9 RD-M6195M w clutch
Brakes - Tektro HD-M3121, Hydraulic, [F] 180mm [R] 160mm
Brake Levers - Tektro HD-M3121
Cassette - Microshift CS-H093 11-46
Chain - KMC X9
Crankset - Prowheel Charm, Steel, 52.5mm chainline, 32t 27,5", 30t for 29" XS: 165mm(27.5"), S: 165mm(27.5")/170mm(29"), M: 170mm(29"), L: 170mm(29")
Bottom Bracket - FP-B902W
Rims - Giant GX03V 27.5"/29" 6061 Aluminum, Double Wall 21mm Inner Width, Disc, 28h
Hubs - alloy, sealed bearing
Spokes - Stainless 14G Steel BED 14G for GU
Tyres - Maxxis Rekon Race 29x2.4" Rekon 27.5x2.4" 60 TPI wire bead
Max Tire Clearance - 29X2.4"
Max Chainring Size - 32T
