Specifications
Frame
ALUXX SL-Grade Aluminium front and rear triangles, Maestro Suspension, 160mm travel, 12x148mm thru-axle, integrated storage solution frame size S/XL: 29"F & 29"R commercial spec and 27.5" rear wheel compatible
Fork
NEW RockShox Zeb Delta RC damper 29"Boost 15x110 Maxle Stealth 170mm
Shock
RockShox SuperDeluxe, R, 205x62,5, custom tuned for Giant, recommended sag 30%
Handlebar
Giant Contact TR35, 800x35mm, 35mm rise,AL6061
Stem
Giant Contact SL 35, Diameter 35mm, 8 degree
Seatpost
Contact Switch AT DSP with remote lever, 30,9mm
Saddle
Giant Romero
Pedals
Al body/AL cage Platform (GC,GT)
Shifters
NEW Shimano Deore SL M6200, 1x12
Rear Derailleur
NEW Shimano Deore RD M7200, Shadow +
Brakes
TRP EVO Comp, black HD-M7040 4 piston
Brake Levers
TRP EVO Comp
Cassette
NEW Shimano Deore, CS M6200 10x51
Chain
KMC X12
Crankset
Praxis Cadet HD M24 Boost, 32T, steel chainring, 55mm chainline with NEW MRP AMg CS Guide, Next generation upper guide
Bottom Bracket
Shimano PressFit Praxis Pressfit
Rims
Giant TRA 2, F29"-R27.5" hookless ALUXX wheelsystem, 30mm IW, 40mm OW, 21mm H,72t POE, 28 j-bend spokes, MS driver body
Hubs
Giant TRA 2, F29"-R27.5" hookless ALUXX wheelsystem, 30mm IW, 40mm OW, 21mm H,72t POE, 28 j-bend spokes, MS driver body
Spokes
Giant TRA 2, F29"-R27.5" hookless ALUXX wheelsystem, 30mm IW, 40mm OW, 21mm H,72t POE, 28 j-bend spokes, MS driver body
Tyres
[F] Maxxis Assegai 29x2.5 WT, 3C MaxxTerra, 60 TPI, EXO+, TR [R] Maxxis Minion DHR II 29 27.5x2,4WT, 3C MaxxTerra, DD 2x60 TPI TR
Extras
MRP AMG CS chain guide for all GSC's, Tubeless Prepared, maximum tire size 2.5", maximum chainring size 36T
Max Tire Clearance
29x2.5"
Max Chainring Size
36T
