Specifications
Sizes - XS, S, M, L
Colours - Morning Haze
Frame - ALUXX SL-grade aluminum front and rear triangles, 140mm Maestro Suspension, 12x148mm thru-axle, flip chip – Maestro 3, flip chip – headset, integrated down tube storage, under-top tube storage mounts
Fork - Fox 36 Float Rhythm, 150mm, GRIP damper, Boost 15x110 Kabolt X, tapered, 44mm offset
Shock - Fox Float Performance, 185x52.5, custom tuned for Liv, recommended sag 30%
Handlebar - Giant Contact TR35, 20mm rise, alloy XS: 760mm, S: 760mm, M: 760mm, L: 780mm
Stem - Giant Contact SL 35 XS: 40mm, S: 50mm, M: 50mm, L: 50mm
Seatpost - Giant Contact Switch AT dropper, remote XS: 140-170mm travel / 30.9 x 470mm S: 140-170mm travel / 30.9 x 470mm M: 170-200mm travel / 30.9 x 530mm L: 170-200mm travel / 30.9 x 530mm
Saddle - Liv Sylvia
Pedals - platform [GC, GT]
Shifters - Shimano Deore, 1x12
Front Derailleur - N/A
Rear Derailleur - Shimano Deore, Shadow +
Brakes - TRP EVO Comp, hydraulic, TRP [F] 203mm, [R] 180mm
Brake Levers - TRP EVO Comp
Cassette - Shimano Deore 6200, 10x51
Chain - KMC X12
Crankset - Praxis Cadet HD M24 Boost, 30t, 55mm chainline XS: 165mm, S: 170mm, M: 170mm, L: 170mm
Bottom Bracket - Praxis, press fit
Rims - Giant TRA 2 wheelset, 6061 alloy, hookless, 30mm inner width, 40mm outer width, 21mm height, Wide Guard Technology XS/S: [F] 29, [R] 27.5 M/L: [F] 29, [R] 29
Hubs - [F] Giant MTB alloy, 6-bolt [R] Giant MTB alloy, 72 POE (Points of Engagement), 6-bolt, MicroSpline driver body
Spokes - Sapim, 28, J-bend
Tyres - Size XS, S, M and L, [F]: Maxxis Assegai 29x2.5WT, 3C Max Terra, EXO, TR, tubeless Size XS and S, [R]: Maxxis Minion DHR II 27.5x2.4WT, 3C Max Terra, EXO, TR, tubeless Size M and L, [R]: Maxxis Minion DHR II 29x2.4WT, 3C Max Terra, EXO, TR, tubeless
Extras - 3M tailgate protector, tubeless prepared, integrated down tube storage bag, max tire size 2.5", max chainring size 34t
