Adapt to the route with the flip chip – dropout, which lets you adjust your wheelbase length and rear-wheel tire clearance. Go shorter for responsive handling and quick acceleration. Go longer for added stability plus clearance for larger tires and extra traction.
Sizing Guide
Sizing to be used as a reference only. Please check with a local authorized dealer to determine the correct size.
Available sizes may vary from country to country.
XS 150 cm - 163 cm
S 158 cm - 169 cm
M 164 cm - 175 cm
L 170 cm - 181 cm
Specifications
Sizes - XS, S, M, L
Colours - Dune Beige
Frame - ALUXX-grade aluminum, 12x142mm thru-axle, flat mount disc, flip chip – dropout
Fork - Advanced-grade composite, full-composite OverDrive steerer, 12mm thru-axle, flat mount disc
Shock - N/A
Handlebar - Giant Contact XR D-Fuse, 31.8mm, 5-degree back sweep, flare drop, XS: 400mm, S: 400mm, M: 420mm, L: 420mm
Stem - Giant Contact, 8-degree, XS: 50mm, S: 60mm, M: 70mm, L: 80mm
Seatpost - Giant D-Fuse, alloy
Saddle - Liv Grit
Shifters - Shimano CUES U6030, 2x10
Front Derailleur - Shimano CUES U6030
Rear Derailleur - Shimano CUES U6020
Brakes - Shimano CUES BR-U6030 hydraulic, Giant MPH rotors, [F]160mm, [R]160mm
Brake Levers - Shimano CUES BR-U6030 hydraulic
Cassette - Shimano CS-LG300, 11x39
Chain - KMC X11 with Missing Link
Crankset - Shimano FC-U6030, 32/46, XS: 165mm, S: 170mm, M: 172.5mm, L: 172.5mm
Bottom Bracket - Shimano, press fit
Rims - Giant S-X2 Disc, alloy
Hubs - Giant alloy, 12mm thru-axle
Spokes - stainless steel
Tyres - Giant CrossCut AT 2, 700x38c, tubeless
Extras - 53mm max tire size in "long" flip chip position, 45mm max tire size in "short" flip chip position, tubeless prepared, ISC clamp
Max Tire Clearance - 53mm
