KEY PERFORMANCE FACTORS

Built for Endurance

Advanced-Grade Composite and OverDrive provide unprecedented pedalling and cornering stiffness on an endurance geometry for all-day riding.

Control

Combines the weight-savings and stability of a compact road frame design with powerful disc brakes for expert handling and control, no matter the weather and road conditions.

Adaptable comfort

The Avail tackles the roads less travelled with larger-size tire compatibility, and a D-Fuse seatpost to soak up bumps.

SIZING GUIDE AND GEOMETRY

XS 153cm to 162cm

S 158cm to 169cm

M 165cm to 174cm

Colours - Dark Jade

Frame - Advanced-Grade Composite, 12x142mm thru-axle, disc

Fork - Advanced-Grade Composite, full-composite OverDrive steerer, 12x100mm, disc

Shock - N/A

Handlebar - Liv Contact SL D-Fuse, 31.8mm XXS:38cm, XS:38cm, S:40cm, M:40cm, L:42cm

Grips - Liv All Condition

Stem - Giant Contact XXS:70mm, XS:70mm, S:80mm, M:90mm, L:90mm

Seatpost - Giant D-Fuse, composite, -5/+15mm offset XXS:350mm, XS:350mm, S:350mm, M:350mm, L:350mm

Saddle - Liv Approach

Pedals - N/A

Shifter - Shimano Ultegra ST-8025

Front Derailleur - Shimano Ultegra

Rear Derailleur - Shimano Ultegra RX-810

Brakes - Shimano Ultegra hydraulic, Shimano rotors [F]160mm, [R]140mm

Brake Levers - Shimano Ultegra

Cassette - Shimano Ultegra, 11-speed, 11x34

Chain - KMC X11EL-1

Crankset - Shimano RS510, 34/50 XXS:165mm, XS:165mm, S:170mm, M:170mm, L:172.5mm

Bottom Bracket - Shimano, press fit

Rims - Giant P-R2 Disc wheelset

Hubs - Giant P-R2 Disc wheelset, 12mm thru-axle

Spokes - Giant P-R2 Disc wheelset

Tyres - Giant Gavia Fondo 1, tubeless, 700x32c (33.5mm), folding

Extras - Tubeless prepared, 35mm max tire size

Weight ~ 8.9kg
